Table 7-8 SIMOTION D410 dimensions and weight
Dimensions W x H x D 73 x 183,2 x 89,6 mm
SIMOTION D410 weight
- Without packaging
- With packaging
990 g
1200 g
CompactFlash card
Table 7-9
CF card
Memory capacity 1 GB (Order No. 6AU1400-2PA0*-0AA0)
512 MB (Order No. 6AU1400-2NA00-0AA0)
Weight 10 g
With CF cards, SIMOTION versions up to and including V4.1 SP1 inc. hotfixes support a
maximum
memory addressing of 512 MB. Limiting is valid for use both by means of SIMOTION
runtime functions and in other capacities, such as document archiving.
If more than 512 MB is saved on the CF card, SIMOTION runtime considers the card to have
been utilized to its full capacity, i.e.
● SIMOTION runtime cannot write any further data,
● SIMOTION runtime cannot read data beyond the 512 MB range.
Note
Please note that
●
In their as-delivered condition, the 1-GB CF cards with order number
6AU1400‑2PA0*‑0AA0 contain firmware that can only run on SIMOTION D4xx modules;
● In their as-delivered condition, the 1-GB CF cards with order number
6AU1400‑*PA2*‑0AA0 contain firmware that can only run on SIMOTION D4xx‑2 modules.
It is also possible to use the 1-GB CF cards for SIMOTION D4xx‑2 (order number
6AU1400‑*PA2*‑0AA0) for SIMOTION D4xx modules by loading the latest boot loader and
the D4xx firmware. The reverse case is also possible. The CF card must only be formatted
with FAT or FAT16, and must not be formatted with FAT32 or NTFS. Note that CF cards for
SIMOTION D4xx‑2 may have FAT32 formatting!
Mounting plate
Table 7-10
Mounting plate data
Dimensions W x H x D 74,5 x 236 x 36,5 mm
Weight
- Without packaging
- With packaging
380 g
450 g
Technical data
7.4 System data, connection values, dimensions and weight
SIMOTION D410
Manual, 04/2014 89
