For more information on "thermal motor protection", see the
SINAMICS S120
Commissioning
Manual.
Note
For
SIMOTION D410, the following safety functions are available with version V4.1 SP2 and
higher:
● Safety Integrated Basic Functions via the EP terminals
● Safety Integrated Extended Functions with TM54F
● Safety Integrated Extended Functions via secure communication from "PROFIsafe to
PROFIBUS"
Control (F logic) is via a SIMATIC F-CPU which is connected to PROFIsafe via
PROFIBUS (e.g. a CPU 317F-2 DP)
For further information on Safety Integrated, see the
SINAMICS S120 Safety Integrated
Function Manual
.
Interface characteristics
Table 4-15
Interface X120
Characteristic Type
Connector type Mini Combicon, 8-pin
Grid 2.5 mm
Maximum connectable cross-section 1.5 mm
2
Interface assignments
Table 4-16
Interface assignment X120
Representation Pin Name Description
1 Reserved, do not use
2 Reserved, do not use
3 G Ground
4 + Temp
1)
KTY or PTC input
5 - Temp
1)
Ground for KTY or PTC
6 Reserved, do not use
7 EP +24 V
2)
Safety Integrated Basic Functions (+)
8 EP M1
2)
Safety Integrated Basic Functions (-)
1)
This is the second temperature channel (T2), which depending on the parameterization, is used as a single channel or in
combination with the first temperature channel (T1, see X23).
2)
The EP terminals must be wired on the Power Module on chassis units.
Interfaces
4.7 EP terminals/temperature sensor connection
SIMOTION D410
56 Manual, 04/2014
