Requirements
You
must order the mounting plate for SIMOTION D410 separately. See Chapter "Spare Parts
and Accessories" for the order number.
Mounting on mounting plate
1. The mounting plate is attached to the control cabinet.
2. SIMOTION D410 is snapped onto the mounting plate.
Figure 5-2 Mounting SIMOTION D410 on the mounting plate
Note
When
operating away from the Power Module, generally the power supply must be realized
via the power supply connection (X124).
Observe the information on control cabinet installation in the
SINAMICS S120 AC Drive
Manual.
Assembling
5.3 Mounting SIMOTION D410 on the mounting plate
SIMOTION D410
Manual, 04/2014 65
