Procedure for connecting encoders
To connect an external encoder (HTL, TTL or SSI encoder), proceed as follows:
1.
Connect the connecting cable to the encoder.
2. Plug the D-Sub connector (15-pin) to the socket X23.
3. Lock the connector using the finger screws.
NOTICE
Destruction of the encoder electronics
Operation of a 5 V encoder on the 24 V encoder supply may result in the destruction of its
electronic components!
Make sure that you can operate the connected encoder on a 24 V power supply (e.g. HTL
encoder).
This setting can be set in the expert list of the drive in parameter p0400 and in the
following parameters.
Connecting
6.11 Connecting an external encoder
SIMOTION D410
84 Manual, 04/2014
