and thus used from the drive side as well. Unlike the TM15, measuring input inputs and cam
outputs are not available with the TM15 DI/DO.
Note
The module hardware for TM15 and TM15 DI/DO is identical. A distinction is only made by
the addition of the component in the SIMOTION SCOUT project navigator using "Inserting I/
O component".
TM17 High Feature
Each
of the 16 DI/DO can be configured on a channel-specific basis as digital input (DI), digital
output (DO), measuring input or output cam output.
TM17 High Feature has fewer I/O channels than TM15, but more functionality. TM17 High
Feature is distinguished by especially high resolution and accuracy as well as a configurable
input filter and enabling inputs (max. 6 units). Parameterized enable inputs can enable
measuring inputs or outputs of output cams (gate function). Due to their high accuracy, the DI/
DO channels of the TM17 High Feature are non-isolated.
Note
NOTICE
Overheating if ventilation clearances are too small
Insufficient ventilation clearances result in overheating and therefore in more failures and a
shortened life of the component.
Maintain 50 mm ventilation clearances above and below the component.
Additional references
Detailed information about the TM15 and TM17 High Feature can be found in the
SIMOTION
Terminal Modules TM15 / TM17 High Feature
Commissioning Manual.
Spare parts/Accessories
8.4 Terminal modules TM15 and TM17 High Feature
SIMOTION D410
98 Manual, 04/2014
