7.3.2 Safety information for the TB30
NOTICE
Damage to the TB30 caused by electric fields or electrostatic discharge
Option boards are ESD-sensitive components.
De-energize the SIMOTION D4x5‑2 device before inserting or removing the option board.
The SIMOTION D4x5‑2 is in a de-energized state when all the LEDs are off.
Observe ESD guidelines; for details, see Section
ESD guidelines (Page 141).
7.3.3 Interfaces
7.3.3.1
Overview
The following figure shows the arrangement of the interfaces on the front of the TB30.
$QDORJLQSXWVRXWSXWV
'LJLWDO,2V
3RZHUVXSSO\IRU
'LJLWDORXWSXWV
7%
;
;
;
Figure 7-5 Interface arrangement on the TB30
Supplementary system components
7.3 TB30 terminal board
SIMOTION D4x5-2
Manual, 04/2014 103
