Operator control (hardware)
3
3.1 Overview of operator control and display elements
The
following figure shows the arrangement of the operator control and display elements of a
SIMOTION D445-2 DP/PN.
2SHUD
WRUFRQWURO
DQGGLVSOD\
HOHPHQWV
$UHDSURWHFWHGE\
EODQNLQJFRYHU
Figure 3-1 Position
of operator control and display elements (example of SIMOTION D445-2 DP/PN)
The lower part of the operator control and display elements has a blanking cover during
operation. This cover is removed for service work.
SIMOTION D4x5-2
Manual, 04/2014 43
