Dimensions and weights
Table 7-29
Dimensions and weight of a SIMOTION CX32‑2
Parameter SIMOTION CX32‑2
Dimensions W x H x D [mm]
(max. expansion)
●
Without fastening using spacers
● With fastening using spacers
● 25 x 380 x 230
● 25 x 380 x 270
Weight CX32‑2 [g]
●
Without packaging
● With packaging
● approx. 2600
● approx. 3150
Ambient conditions
The
following conditions apply to modules that are shipped and stored in the original packaging.
Table 7-30 CX32‑2 environmental requirements
Parameter Values
Permissible ambient temperature
● Transport
●
Long-term storage
● Operation
● -40 °C ... +70 °C
● -25 °C ... +55 °C
● 0° C ... +55° C up to 2000 m above sea level.
As of an altitude of 2000 m, the maximum ambient
temperature decreases by 7° C every 1000 m
increase in altitude
Atmospheric pressure 620 ... 1060 hPa
Permissible relative humidity
● During transport and storage
● During
operation (condensation, icing, drip,
spray and splash water not permitted)
● 10 % ... 100 %
● 5 % ... 90 %
Installation altitude Max. 4,000 m above sea level.
For SINAMICS S120 drive components, see
SINAMICS Manuals.
Biological environmental conditions
●
Storage
● Transport
● Operation
● Class 1B1 according to EN 60 721‑3‑1
● Class 2B1 according to EN 60 721‑3‑2
● Class 3B1 according to EN 60 721‑3‑3
Degree of protection according to EN 60529
(IEC 60529)
IP20
Pollution degree 2 according to EN 60 664‑1
