Note
SIMOTION D425‑2 DP and D435‑2 DP must be operated with a double fan/battery module
for heat dissipation. Without this module, the Control Units will not start up and cannot be
commissioned.
Information on how to install the double fan/battery module can be found in "Supplementary
system components", in Section
Installing the fan/battery module (Page 99).
Note
SIMOTION
D425‑2 DP and D435‑2 DP are supplied with pre-assembled spacers. These can
be removed if necessary.
For further details, see the
SIMOTION D4x5‑2
Commissioning and Hardware Installation
Manual.
Description
2.4 Representation of SIMOTION D425-2 DP and D435-2 DP
SIMOTION D4x5-2
32 Manual, 04/2014
