Interface assignment of X122, X132 and X142
Table 4-8
Digital inputs/outputs X122
Pin Designation
1)
Signal type
2)
Notes
1 DI 0 I Digital input 0
2 DI 1 I Digital input 1
3 DI 2 I Digital input 2
4 DI 3 I Digital input 3
5 DI 16 I Digital input 16
6 DI 17 I Digital input 17
7 M1 GND Ground for DI 0 – DI 3, DI 16, DI 17 (electrically isolated relative
to M)
8 M GND Ground
9 DI/DO 8 B Digital input/output 8 (can also be used as input for measuring
input or as input for the external zero mark)
10 DI/DO 9 B Digital input/output 9 (can also be used as input for measuring
input or as input for the external zero mark)
11 M GND Ground
12 DI/DO10 B Digital input/output 10 (can also be used as input for measuring
input or as input for the external zero mark)
13 DI/DO 11 B Digital input/output 11 (can also be used as input for measuring
input or as input for the external zero mark)
14 M GND Ground
1)
DI: Digital input; DI/DO: Bidirectional digital input/output; M: Electronics ground;
M1: Ground reference
2)
B = Bidirectional; I = Input; GND = Reference potential (ground)
Table 4-9
Digital inputs/outputs X132
Pin Designation
1)
Signal type
2)
Notes
1 DI 4 I Digital input 4
2 DI5 I Digital input 5
3 DI 6 I Digital input 6
4 DI 7 I Digital input 7
5 DI 20 I Digital input 20
6 DI 21 I Digital input 21
7 M2 GND Ground for DI 4 – DI 7, DI 20, DI 21 (electrically isolated relative
to M)
8 M GND Ground
9 DI/DO 12 B Digital input/output 12 (can also be used as input for measuring
input or as input for the external zero mark)
Interfaces
4.4 Digital I/Os
SIMOTION D4x5-2
Manual, 04/2014 61
