Features Type
Flexible, with wire-end ferrule without plastic
sleeve
0.2 mm² … 2.5 mm²
Flexible, with wire-end ferrule with plastic
sleeve
0.2 mm² … 1.5 mm²
AWG / kcmil 22 … 12
Stripped length 6 … 7 mm
Tool Screwdriver 0.5 x 3 mm (M2.5)
Tightening torque 0.4 to 0.5 Nm
Max. current carrying capacity, incl. loop-through 20 A (15 A per UL/CSA)
Max. cable length 10 m
Interface assignments
Table 4-13 Power supply X124
Pin Signal name Meaning
1 + Power supply 24 V
2 + Power supply 24 V
3 G Ground
4 G Ground
Note
The
24 V is looped through via the 24 V connector. In this case, pin 1 is jumpered with pin 2,
and pin 3 is jumpered with pin 4 in the connector. The maximum current can be limited through
the current carrying capacity of the cable. The current carrying capacity of the cable depends,
for example, on the type of cable installation (cable duct, laying on a cable rack, etc.).
Interfaces
4.5 Power supply
SIMOTION D4x5-2
Manual, 04/2014 65
