Interface characteristics
Table 4-14
X127 P1 and X130 P1 (X120 P1 only for SIMOTION D4x5-2 DP)
Characteristic Type
Connector type RJ45 socket connector
Cable type Industrial Ethernet cable
●
4‑ and 8‑wire cables can be used for 10/100 Mbit/s
● 8‑wire cables must be used for 1000 Mbit/s
Max. cable length 100 m
Autocrossing Yes
Dust protection filler plugs for sealing
unused Ethernet ports
5 filler plugs contained in the D4x5‑2 scope of delivery
Filler plugs (50 pcs) order number: 6SL3 066‑4CA00‑0AA0
Miscellaneous X127 P1, X120 P1 and X130 P1 are full‑duplex 10/100/1000 Mbit/s Ethernet ports
Pin assignment
Table 4-15
X127 P1 and X130 P1 Ethernet interfaces (X120 P1 only for SIMOTION D4x5-2 DP)
Representati
on
Pin Assignment in 10/100 Mbit mode Assignment in 1 Gbit mode
Signal name
1)
Sign
al
type
Meaning Signal name
1)
Signal type Meaning
1 TXP O Ethernet
transmit
differential
signal
DA+ B Bidirectional
pair A+
2 TXN O Ethernet
transmit
differential
signal
DA- B Bidirectional
pair A-
3 RXP I Ethernet
receive
differential
signal
DB+ B Bidirectional
pair B+
4 - - - - - - Reserved, do
not use
DC+ B Bidirectional
pair C+
5 - - - - - - Reserved, do
not use
DC B Bidirectional
pair C-
6 RXN I Ethernet
receive
differential
signal
DB- B Bidirectional
pair B-
7 - - - - - - Reserved, do
not use
DD+ B Bidirectional
pair D+
Interfaces
4.6 Ethernet interfaces
SIMOTION D4x5-2
Manual, 04/2014 69
