1)
Sensors: Fail-safe devices for commanding and detecting, such as emergency stop
pushbuttons and safety locks as well as position switches and light arrays / light curtains.
2)
Dynamic
response: The sensor power supply is switched on and off during test stop for testing
the sensors, the cable routing, and the evaluation electronics of TM54F.
The TM54F has 4 fail-safe digital outputs and 10 fail-safe digital inputs. A fail-safe digital output
consists of a P/M-switching output as well as a digital input for reading back the switching
state. A fail-safe digital input is made up of two digital inputs.
NOTICE
Overheating if ventilation clearances are too small
Insufficient ventilation clearances result in overheating and therefore in more failures and a
shortened life of the component.
Maintain 50 mm ventilation clearances above and below the component.
Additional references
You will find detailed information on the TM54F Terminal Module in the following sources:
●
SINAMICS S120 Control Units and Additional System Components
Manual
●
SINAMICS S120 Safety Integrated
Function Manual
7.9 TM15 and TM17 High Feature terminal modules
Features of TM15 and TM17 High Feature
The TM15 and TM17 High Feature Terminal Modules are used to implement inputs of
measuring inputs and outputs of output cams for SIMOTION D. In addition, these Terminal
Modules provide drive-related digital I/Os with short signal delay times. TM15 and TM17 High
Feature are connected via DRIVE‑CLiQ.
TM15
Each of the 24 electrically isolated digital I/Os can be parameterized channel-by-channel as
a digital input (DI), digital output (DO), a measuring input input, or an output cam output.
TM15 DI/DO
Each of the 24 isolated digital I/Os can be configured on a channel-specific basis as a digital
input (DI) or digital output (DO). The digital I/Os can be interconnected using BICO technology
and thus used from the drive side as well. Unlike the TM15, measuring input inputs and cam
outputs are not available with the TM15 DI/DO.
Note: The module hardware for TM15 and TM15 DI/DO is identical. A distinction is only made
by the addition of the component in the SIMOTION SCOUT Project Navigator using "Inserting
input/output component."
Supplementary system components
7.9 TM15 and TM17 High Feature terminal modules
SIMOTION D4x5-2
132 Manual, 04/2014
