Note
If
the D4x5‑2 detects undervoltage, the module performs a RESET. If all LEDs are off, either
there is no power supply or the voltage level is too low.
When the voltage level is in the permissible range again, the D4x5‑2 restarts.
Undervoltages are detected when:
● The voltage level of the 24-V supply falls below the minimum permissible input voltage of
the D4x5-2
● A temporary voltage dip (> 3 ms) results in the supply falling below the minimum
permissible input voltage on the D4x5‑2.
Additional references
Recommended power supply units and tables for calculating the current consumption for the
assembly
with SINAMICS S120 modules can be found in the "Control cabinet installation and
EMC booksize" chapter in the
SINAMICS S120 Booksize Power Units Manual.
5.5 Interfaces and performance features
Memory for system data
Table 5-9 Memory for system data and its memory size
Data Memory size
D425-2
Memory size
D435-2
Memory size
D445-2 DP/PN
Memory size
D455‑2 DP/PN
Diagnostic buffer
(non-volatile)
200 messages
(SIMOTION)
200 messages
(SINAMICS
Integrated)
200 messages
(SIMOTION)
200 messages
(SINAMICS
Integrated)
200 messages
(SIMOTION)
200 messages
(SINAMICS
Integrated)
200 messages
(SIMOTION)
200 messages
(SINAMICS
Integrated)
RAM (working
memory)
1)
48 MB 64 MB 128 MB 256 MB
RAM disk (load
memory)
31 MB 41 MB 56 MB (as of V4.3)
50 MB
76 MB (as of V4.3)
50 MB
Retentive memory 364 KB 364 KB 512 KB 512 KB
Persistent memory
(user data on CF)
1-GB CF: 300
MB
1-GB CF: 300 MB 1-GB CF: 300 MB 1-GB CF: 300 MB
1)
A separate 20 MB of working memory is available for Java applications.
