Ethernet
The control unit can communicate with the following components via the Ethernet interfaces
or be embedded in an automation environment:
Table 2-4
Components on the Ethernet
Component Function
Programming device (PG/PC) ... configures, parameterizes, programs, and tests with the
"SIMOTION SCOUT" engineering system (ES)
Master computer ... communicates with other devices via UDP, TCP/IP
SIMATIC HMI device ... is used for operating and monitoring functions. This is not an
essential requirement for the operation of a control unit.
PROFINET IO
The D4x5‑2 DP/PN can communicate with the following components via the onboard
PROFINET IO interface or via the Ethernet communication board (CBE30-2).
Table 2-5
Components on the PROFINET IO
Component Function
Programming device (PG/PC) ... configures, sets parameters, programs, and tests using the
"SIMOTION SCOUT" Engineering System (ES).
SIMATIC HMI device ... is used for operating and monitoring functions. This is not an
essential requirement for the operation of a control unit.
Other controllers (e.g.
SIMOTION or SIMATIC)
... e.g. higher-level controller (plant controller); modular machine
concepts with multiple controllers, distributed across individual
machine modules.
Master computer ... communicates with other devices via UDP, TCP/IP.
Distributed I/O systems
SIMATIC ET 200MP Modular I/O system for cabinet installation and high channel
densities in the SIMATIC S7‑1500 packaging system.
SIMATIC
ET 200MP permits the shortest bus cycle times and fastest
response time even with large volumes of data.
SIMATIC ET 200M Modular I/O system for cabinet installation and high channel
densities in the SIMATIC S7‑300 packaging system.
SIMATIC ET 200SP Finely scalable I/O system for cabinet installation; ET 200SP
features a single-cable and multi-cable connection with push‑in
terminals, compact dimensions, high performance, and low part
variety.
SIMATIC ET 200S Finely scalable I/O system for control cabinet configuration and
particularly
time-critical applications; including motor starters, safety
technology and individual grouping of load groups.
SIMATIC ET 200pro Modular I/O system with IP65/67 degree of protection for machine-
related applications with no control cabinet; with features such as
compact designs, integrated PROFIsafe safety technology,
PROFINET IO connection and live module replacement.
SIMATIC ET 200eco PN Compact block I/O with IP65/66/67 degree of protection for cabinet-
free usage in machines with M12 connection method. Very rugged
and resistant encapsulated metal enclosure.
Description
2.2 System components
SIMOTION D4x5-2
Manual, 04/2014 27
