11.98 Transport, unpacking, assembly
Siemens AG 6SE7087-6AC85-0AA0 ENGLISH
2-3
Common Rectifier Operating instructions
2.4 Dimension drawings
Air intake
SIEMENS
X9
X1
U1 V1
W1 C D
X36
5 4 3 2 1
1
2
F2
X1
X37
X20
V1
S2
R2
SIEM ENS
WARNUNG
DANGER
41
23
20
35
R100
V1
25
X1
X9
25
Fiew without front cover
2)
3)
6)
5)
4)
2)
6)
1)
40
4)
PE
Exhaust air
Front view
Top view
1) Mounting hole for screw M6.
2) Hook (suspension) for mounting on a
g-rail according to EN50035
3) Space required for cooling the unit.
4) Screen connection for two cables.
5) Shock-hazard protection
6) Connector for power supply DC24V
and fault signal
No displacement of the centre of gravity
Weight: approx. 12kg
Dimension: mm
350
100
3)
100
50
125
16
425
135
67,5
225
X36
47
425
A23
A23
max. 5,7
Detail Z
Z
S1
F1
S3
S3
S1
Figure 2.2 Size B
