Siemens SIMOVERT 6SE7024-1EB85-0AA0 User Manual

02.96 Spare parts
Siemens AG 6SE7087-6AC85-0AA0 ENGLISH
10-1
Common Rectifier Operating instructions
10 Spare parts
For common rectifiers, sizes B and C
Equipment
identifier
Designation Order number Used in
-A23 Resistor precharging pc board 6SE7024-1EB85-0FA0 6SE7024-1EB85-0AA0
6SE7024-1FB85-0FA0 6SE7024-1FB85-0AA0
-A23 Control pc board 6SE7028-6EC85-0CA0 6SE7028-6EC85-0AA0
6SE7028-8FC85-0CA0 6SE7027-2FC85-0AA0
6SE7028-8FC85-0AA0
-A24 Precharging pc board PCU0 6SE7024-7FD84-1HH0 6SE7024-1FB85-0AA0
6SE7027-2FC85-0AA0
6SE7028-8FC85-0AA0
-E1 Fan 6SY7000-0AA48 all unit types
1)
-V1 Bridge rectifier 6SY7010-1AA01 6SE7024-1EB85-0AA0
-V1 Bridge rectifier 6SY7010-1AA02 6SE7024-1FB85-0AA0
-V1 Bridge rectifier 6SY7010-1AA03 6SE7028-6EC85-0AA0
-V1 Bridge rectifier 6SY7010-1AA04 6SE7027-2FC85-0AA0
-V1 Bridge rectifier 6SY7010-1AA05 6SE7028-8FC85-0AA0
-F1 Fuse link 6SY7010-2AA01 all unit types
-F2 Fuse link 6SY7010-2AA02 all unit types
-R100 NTC thermistor 6SY7010-6AA01 all unit types
Table 10.1 Spare parts
1) optional in the case of 36A units (6SE7024-1xB85)
