Electrical Connections
4.1 Power cable
Caution
When engineering the system it must be checked to ensure that the power cable can be
connected to the power module.
Assignment: Motor - cable cross-section - terminal box - power connector
The assignment: Motor - cable cross-section - terminal box - power connector is described in
the appropriate Motor Configuration Manual.
General Section for Synchronous Motors
4-2 Configuration Manual, (PJAL), 11.2005 Edition, 6SN1 197-0AD07-0BP4
