Electrical Connections
4.2 Order Nos. for power cables
General Section for Synchronous Motors
Configuration Manual, (PJAL), 11.2005 Edition, 6SN1 197-0AD07-0BP4
4-3
4.2 Order Nos. for power cables
4.2.1 Overview
Prefabricated cables reduce the mounting/installation time and costs and increase the
operational reliability.
Power cables available for synchronous motors:
• Prefabricated cable without brake conductors with overall shield
• Prefabricated cable with brake conductors with overall shield
• Cable sold by the meter without brake conductors with overall shield
• Cable sold by the meter with brake conductors with overall shield
Caution
Carefully observe the current which the motor draws for your particular application!
Adequately dimension the connecting cables according to IEC 60204-1.
Explanation of Order No. for the power cables
6FX ☐ 00 ☐ - ☐☐☐☐☐ - ☐☐☐ 0
↓ ↓ ↓ ↓↓↓
↓ ↓ Length code
↓ Type, cross-section, connector size
↓
↓
↓
↓
2 = prefabricated
8 = sold by the meter
5 = MOTION-CONNECTⓇ500
8 = MOTION-CONNECTⓇ800
