Electrical Connections
4.2 Order Nos. for power cables
General Section for Synchronous Motors
4-4 Configuration Manual, (PJAL), 11.2005 Edition, 6SN1 197-0AD07-0BP4
Length code
Table 4-2 Length codes for prefabricated cables
Cables, prefabricated
Length code 6FX2002-.....-
6FX5002-.....-
6F82002-.....-
☐
☐
☐
☐
☐
☐
☐
☐
☐
0
0
0
1 m – 99 m
100 m – 199 m
200 m – 299 m
1
2
3
0 m
10 m
20 m
30 m
40 m
50 m
60 m
70 m
80 m
90 m
A
B
C
D
E
F
G
H
J
K
0 m
1 m
2 m
3 m
4 m
5 m
6 m
7 m
8 m
9 m
A
B
C
D
E
F
G
H
J
K
Examples:
1 m
2 m
5 m
10 m
15 m
18 m
20 m
25 m
50 m
100 m
150 m
6FX☐00☐-☐☐☐☐☐-1AB0
6FX☐00☐-☐☐☐☐☐-1AC0
6FX☐00☐-☐☐☐☐☐-1AF0
6FX☐00☐-☐☐☐☐☐-1BA0
6FX☐00☐-☐☐☐☐☐-1BF0
6FX☐00☐-☐☐☐☐☐-1BJ0
6FX☐00☐-☐☐☐☐☐-1CA0
6FX☐00☐-☐☐☐☐☐-1CF0
6FX☐00☐-☐☐☐☐☐-1FA0
6FX☐00☐-☐☐☐☐☐-2AA0
6FX☐00☐-☐☐☐☐☐-2FA0
