Electrical Connections
4.2 Order Nos. for power cables
General Section for Synchronous Motors
Configuration Manual, (PJAL), 11.2005 Edition, 6SN1 197-0AD07-0BP4
4-7
4.2.5 Power cable sold by the meter with brake conductors
Order No.
6FX ☐ 008 - 1☐ A☐☐- ☐☐☐ 0
↓ ↓ ↓ ↓↓↓
↓ Length code ↓
↓ With brake conductors
↓
↓
↓ 8 = sold by the meter
5 = MOTION-CONNECTⓇ500
8 = MOTION-CONNECTⓇ800
4.2.6 Signal cable
We recommend that prefabricated cables from SIEMENS are used. In addition to having the
security of knowing that they function perfectly and are high quality products, there are also
some associated cost benefits.
The signal cables must be routed separately away from the power cables in order to avoid
noise and disturbances being coupled in.
Note
The maximum possible cable lengths, listed in the connection overviews, must be carefully
observed.
The signal cables used are described in the appropriate Motor Configuration Manual.
