Technical Data 10.99
6SE7087-6KP50 Siemens AG
11-2 Operating Instructions SIMOVERT MASTERDRIVES
Mechanical strength
- Vibration
During stationary duty:
const. amplitude
• deflection
• acceleration
During transport:
• deflection
• accleration
- Shocks
- Drop
According to DIN IEC 68-2-6
0.15 mm in frequency range 10 Hz to 58 Hz
(housing width ≤ 90 mm)
0.075 mm in frequency range 10 Hz to 58 Hz
(housing width ≥ 135 mm)
9.8 m/s² in frequency range > 58 Hz to 500 Hz
(housing width ≥ 135 mm)
19.6 m/s² housing width ≤ 90 mm
3.5 mm in frequency range 5 Hz to 9 Hz
9.8 m/s² in frequency range > 9 Hz to 500 Hz
According to DIN IEC 68-2-27 / 08.89
30 g, 16 ms half-sine shock
According to DIN IEC 68-2-31 / 04.84
onto a surface and onto an edge
Table 11-1 General data
