10.99 Faults and Alarms
Siemens AG 6SE7087-6KP50
SIMOVERT MASTERDRIVES Operating Instructions 12-3
Number / Fault Cause Counter-measure
F027
Pulse resistor fault /
UCE Phase L3
Pulse resistance fault (only Compact PLUS) /
UCE Phase L3 (chassis)
- Check the converter outputs for earth fault
- Check the switch for "Safe OFF" on Compact
units
F029
Meas. value sensing
Compact PLUS only
A fault has occurred in the measured value
sensing system:
- (r949 = 1) Offset adjustment in phase L1 not
possible
- (r949 = 2) Offset adjustment in phase L3 not
possible.
- (r949 = 3) Offset adjustment in phases L1
and L3 not possible.
- (r949=65) Autom. Adjustment of the analog
inputs is not possible
Fault in measured value sensing
Fault in power section (valve cannot block)
Fault on CU
F035
External fault 1
Parameterizable external fault input 1 has
been activated.
- Check whether there is an external fault
- Check whether the cable to the
corresponding digital output is interrupted
- P575 (Src No ExtFault1)
F036
External fault 2
Parameterizable external fault input 2 has
been activated.
- Check whether there is an external fault
- Check whether the cable to the
corresponding digital output is interrupted
- P576 (Src No ExtFault2)
F038
Voltage OFF during
parameter storage
A voltage failure has occurred during a
parameter task.
Re-enter the parameter. The number of the
parameter concerned is indicated in fault value
r949.
F040
Internal fault of
sequence control
Incorrect operating status Replace the control board (CUMC) or the unit
(Compact PUS).
F041
EEPROM fault
A fault has occurred during the storage of
values in the EEPROM.
Replace the control board (CUMC) or the unit
(Compact PLUS)
F042
Time slot overflow
The available calculating time of the time slot
has been exceeded.
- Reduce pulse frequency
- Calculate individual blocks in a slower
sampling time
F043
DSP link
The link to the internal signal processor is
interrupted
- Reduce pulse frequency (perhaps caused by
calculating time overflow)
- If fault re-occurs, replace the board/unit
F044
BICO manager fault
A fault has occurred in the softwiring of
binectors and connectors
Fault value r949:
>1000: Fault during connector softwiring
>2000: Fault during binector softwiring
- Voltage OFF and ON
- Factory setting and new parameterization
- Exchange the board
1028:Link memory is full. The link area
between the two processors is full. No further
connectors can be transferred.
- Reduction of the linked connections between
the two processors. Interface between the two
processors is position control/setpoint
conditioning i.e.softwires from and to the
setpoint conditioning, position controller,
speed controller, torque interface and current
controller which are not necessary should be
dissolved to reduce the link (value 0).
