Siemens SINAMICS DCM Compact User Manual

12-pulse series connection
4.2 Configuration
12-pulse applications
Compact User Manual, 09/2015, A5E34871844H
35
resistors or of one of the converters can, for example, result in an impermissible increase in
the thyristor reverse voltages.
For this reason, the maximum input voltage depending on the device types (according to the
following table) must not be exceeded by any device:
MLFB
device type
Max. input voltage
[V
rms
]
MLFB
device type
Max. input voltage
[V
rms
]
MLFB
device type
Max. input voltage
[V
rms
]
6RA8013-6DV62
2 x 300
6RA8078-6FV62
2 x 300
6RA8091-6FS22
2 x 300
6RA8013-6FV62 2 x 300 6RA8081-6DS22 2 x 300 6RA8091-6FV62 2 x 300
6RA8018-6DV62
2 x 300
6RA8081-6DV62
2 x 300
6RA8093-4DS22
2 x 300
6RA8018-6FV62
2 x 300
6RA8081-6GS22
2 x 300
6RA8093-4DV62
2 x 300
6RA8025-6DS22
2 x 300
6RA8081-6GV62
2 x 300
6RA8093-4GS22
2 x 300
6RA8025-6DV62
2 x 300
6RA8082-6FS22
2 x 300
6RA8093-4GV62
2 x 300
6RA8025-6FS22
2 x 300
6RA8082-6FV62
2 x 300
6RA8093-4KS22
2 x 500
6RA8025-6FV62
2 x 300
6RA8085-6DS22
2 x 300
6RA8093-4KV62
2 x 500
6RA8025-6GS22
2 x 300
6RA8085-6DV62
2 x 300
6RA8093-4LS22
2 x 500
6RA8025-6GV62
2 x 300
6RA8085-6FS22
2 x 300
6RA8093-4LV62
2 x 500
6RA8028-6DS22
2 x 300
6RA8085-6FV62
2 x 300
6RA8095-4DS22
2 x 300
6RA8028-6DV62
2 x 300
6RA8085-6GS22
2 x 300
6RA8095-4DV62
2 x 300
6RA8028-6FS22
2 x 300
6RA8085-6GV62
2 x 300
6RA8095-4GS22
2 x 300
6RA8028-6FV62
2 x 300
6RA8086-6KS22
2 x 345
6RA8095-4GV62
2 x 300
6RA8031-6DS22
2 x 300
6RA8086-6KV62
2 x 345
6RA8095-4KS22
2 x 500
6RA8031-6DV62
2 x 300
6RA8087-6DS22
2 x 300
6RA8095-4KV62
2 x 500
6RA8031-6FS22
2 x 300
6RA8087-6DV62
2 x 300
6RA8095-4LS22
2 x 500
6RA8031-6FV62
2 x 300
6RA8087-6FS22
2 x 300
6RA8095-4LV62
2 x 500
6RA8031-6GS22
2 x 300
6RA8087-6FV62
2 x 300
6RA8096-4GS22
2 x 300
6RA8031-6GV62
2 x 300
6RA8087-6GS22
2 x 300
6RA8096-4GV62
2 x 300
6RA8075-6DS22 2 x 300 6RA8087-6GV62 2 x 300 6RA8096-4MS22 2 x 500
6RA8075-6DV62
2 x 300
6RA8088-6LS22
2 x 500
6RA8096-4MV62
2 x 500
6RA8075-6FS22
2 x 300
6RA8088-6LV62
2 x 500
6RA8097-4GS22
2 x 300
6RA8075-6FV62
2 x 300
6RA8090-6GS22
2 x 300
6RA8097-4GV62
2 x 300
6RA8075-6GS22
2 x 300
6RA8090-6GV62
2 x 300
6RA8097-4KS22
2 x 500
6RA8075-6GV62
2 x 300
6RA8090-6KS22
2 x 500
6RA8097-4KV62
2 x 500
6RA8078-6DS22
2 x 300
6RA8090-6KV62
2 x 500
6RA8098-4DS22
2 x 300
6RA8078-6DV62
2 x 300
6RA8091-6DS22
2 x 300
6RA8098-4DV62
2 x 300
6RA8078-6FS22
2 x 300
6RA8091-6DV62
2 x 300
6RA8000-0MV62
2 x 500
If higher input voltages are present, SINAMICS DC MASTER Control Modules should be
used in connection with suitable external power units in order to achieve the required proof
voltage. The corresponding systems are available on request.
