Siemens SINAMICS G120 - Page 74

Technical specifications
Power Module PM240
74 Hardware Installation Manual, 07/2009, A5E00807525B AD
Table 6- 10 Frame Sizes F, 3 AC 380 V … 480 V, ± 10%
Order No. unfiltered 6SL3224- 0BE38-8UA0 0BE41-1UA0
kW 90 110 Rated power based on HO-
loading
hp 125 150
Power loss kW 2.4 2.5
Rated input current (HO) A 205 235
Rated output current (HO) A 178 205
Rated input current (LO) A 234 284
Rated output current (LO) A 205 250
Fuse A 250 315
l/s 150.0 150.0 Required cooling air flow
CFM 320 320
mm
2
35.0 … 120 35.0 … 120 Input cable /
Output cable
AWG 2 … 4/0 2 … 4/0
kg 39 39 Weight
lb 90 90
Table 6- 11 Frame Sizes GX, 3 AC 380 V … 480 V, ± 10%
Order No. unfiltered 6SL3224- 0XE41-3UA0 0XE41-6UA0 0XE42-0UA0
kW 132 160 200 Rated power based on HO-
loading
hp 177 215 268
Power loss kW 3.9 4.4 5.5
Rated input current (HO) A 245 297 354
Rated output current (HO) A 250 302 370
Rated input current (LO) A 297 354 442
Rated output current (LO) A 302 370 477
Fuse A 355 400 630
l/s 360 360 360 Required cooling air flow
CFM 760 760 760
mm
2
95 ... 240 120 ... 240 185 ... 240 Input cable /
Output cable
AWG 3/0 ... 600 4/0 ... 600 6/0 ... 600
kg 176 176 176 Weight
lb 388 388 388
