Damage caused by incorrectly opening doors
If you incorrectly open the doors, then this can damage the locking mechanism.
● Open the doors as described in Section "Preparing for use".
See also
Opening the device (Page 106)
Overheating caused by closed water valves
If the water valves are closed, when operational the drive can overheat. This can damage the
components.
● Open all of the water valves after installing the drive.
5.2 Tools required
You require the following tools for mounting and installation:
● Wrench or socket wrench, width across the flats 10, 13, 16/17, 18/19
● Allen key, size 8
● Torque wrench up to 50 Nm
● Screwdriver, size 2
● Torx T20 and T30 screwdrivers
5.3 Screwing the transport units together
NOTICE
Material damage caused by mechanical pressure on components
Stress that occurs during transport may exert mechanical pressure on the components.
Material damage can result.
● Line the cabinets up precisely with each other in order to avoid shearing forces when the
base units are screwed together.
● Install the converter only on a level and horizontal surface.
Preparation
Ensure that access to the holes in the bottom of the cabinets is unobstructed. Remove the
guard covers.
Assembly
5.3 Screwing the transport units together
SINAMICS PERFECT HARMONY GH150 6SL38253AE412AA1-Z
74 Operating Instructions Rev.201910281231 EXAMPLE
