Siemens SINUMERIK 802C Diagnostics Guide

1 Alarms 01.02
6FC5598-3AA20-0BP2 © Siemens AG 2002 All Rights Reserved
1-102 SINUMERIK 802S/802C (DG)
No./Name Explanation Not allowed if Remedy
67. PROGMODEDRYRUN
OFF
Deactivate test
run
(VDI signal:
Rapid traverse
superimposition
l)
1. too high nesting depth
2. the current block in which program
execution is stopped cannot be
reorganized, since deceleration is
carried out over several blocks.
⇒ Wait until the preceding
ASUP is completed, or abort
program
⇒ Abort program
68. BLOCKREADINHIBIT_
ON
Activate read-in
disable for main
run block (VDI
signal: Read-in
inhibit)
69. BLOCKREADINHIBIT_
OFF
Deactivate read-
in disable for
main run block
(VDI signal:
Read-in inhibit)
70. STOPATEND_ALARM Stop at end of
block (alarm)
71. STOP_ALARM Stop all axes
(alarm)
72. PROGESTON Activate program
test
(VDI signal:
Program test)
1. tool management is active.
2. the NCK channel condition is not
READY
⇒ Save tool data
⇒ Press RESET to abort pro-
gram or process, or wait for
end of program
73. PROGTESTOFF Deactivate
program test
(VDI signal:
Program test)
NCK channel condition is not READY
⇒ Press RESET to abort pro-
gram or process, or wait for
end of program
74. STOPATIPOBUFFER_
ISEMPTY_ALARM
Stop at end of
block preparation
(alarm)
75. STOPATIPOBUF_
EMPTY_ALARM_
REORG
Stop at end of
block preparation
with following
reorganization of
block execution
(alarm)
nesting depth too high
⇒ Wait until preceding Asup is
completed, or abort program
76. CONDITIONAL_STOP
ATEND
Conditioned stop
at end of block (If
after continuation
by NC Start a
reason for stop
"Stop at end of
block" is still
provided, Stop is
carried out
again.)
77. CONDITIONAL_SBL_
DEC_STOPATEND
Conditioned stop
at end of block
(Despite of start,
no block is
moved by the
interpreter or
advance to the
main run.)
78. INTERPRETERSTOP_
ALARM
Stop block
search (alarm)
79. RETREAT_MOVE_
THREAD
Retraction
movement in the
case of G33 and
stop.
80. WAITMC Conditioned
waiting for
program marker
(NC block:
WAITMC)
81. SETM Set marker (NC
block: SETM)
82. CLEARM Delete marker
(NC block:
CLEARM)
83. BLOCK_SELECT Select NC block
(PI command)
