Siemens SINUMERIK 802C Diagnostics Guide

01.02 1 Alarms
© Siemens AG 2002 All Rights Reserved 6FC5598-3AA20-0BP2
SINUMERIK 802S/802C (DG) 1-101
No./Name Explanation Not allowed if Remedy
51. NEWCONF Sets all machine
data with
(NEW_CONF)
attribute to active
state
(PI command)
52. CLEARCANCELALARM Delete all alarms
with
CANCELCLEAR
clear condition
(PI command,
Quit Alarm key)
53. BLOCKSEARCHUN_
CONTINUE
Continue block
search.
(NC block,
Stopre)
54. BLOCKSEARCHRUN_
START
Start block
search.
(PI command)
55. BLOCKSEARCHRUN_
RESUME
Continue block
search
(PI command)
56. DIGITIZEON Activate digitali-
zation (PI com-
mand)
57. DIGITIZEOFF Deactivate
digitalization (PI
command)
58. FUNCTGENON Switch on func-
tion generator (PI
command)
59. FUNCTGENOFF Switch off func-
tion generator (PI
command)
60. WAITM Wait for program
marker (channel
communication,
NC block:
WAITM)
61. WAITE Wait for end of
program (channel
communication,
NC block:
WAITE)
62. INIT_SYNC Program selec-
tion from another
channel, syn-
chronization
(Channel com-
munication, NC
block: INIT)
63. MMC_CMD Wait until ac-
knowledgment
from MMC (NC
block,
MMC_CMD)
64. PROGMODESLASHON Activate block sip
of blocks that can
be skipped (VDI
signal: Skip
block)
too high nesting depth
⇒ Wait until the preceding
ASUP is completed, or abort
program
65. PROGMODESLASH
OFF
Deactivate block
skip of blocks
that can be
skipped (VDI
signal: Skip
block)
too high nesting depth
⇒ Wait until the preceding Asup
is completed, or abort pro-
gram
66. PROGMODEDRYRUN
ON
Activate test run
(VDI signal:
Rapid traverse
superimposition)
1.
too high nesting depth
2.
the current block in which program
execution is stopped cannot be
reorganized, since deceleration is
carried out over several blocks.
⇒ Wait until the preceding
ASUP is completed, or abort
program
⇒ Abort program
