Siemens SINUMERIK 802C Diagnostics Guide

01.02 1 Alarms
© Siemens AG 2002 All Rights Reserved 6FC5598-3AA20-0BP2
SINUMERIK 802S/802C (DG) 1-97
No./Name Explanation Not allowed if Remedy
7. MODESWITCHTOHAND-MODE Changing from
the operating
mode to a man-
ual mode
(VDI signal:
JOG,
TEACH_IN,
REF)
1. too high nesting depth:
Various events (e.g. interrupt) may
interrupt execution of the current
program. Depending on the par-
ticular event, ASUP programs are
activated.
These ASUP programs can be
aborted in the same manner as
the user program. For memory
reasons, any nesting depth of the
ASUP programs is not possible.
2. the channel is active (program
running, block search, loading of
machine data)
3. a channel has left the mode group
because of an interrupt.
4. Overstore or Digitalize is selected.
⇒ Press RESET to abort the
program
⇒ Press RESET to abort the
program or stop the program
(not during block search or
machine data loading)
⇒ Press RESET to abort the
program or wait until the inter-
rupt is completed.
⇒ Deselect Overstore / Digital-
ize
8. OVERSTOREON Selection of
Overstore mode
(PI command).
9. OVERSTOREOFF Deselection of
Overstore mode
(PI command).
10. SYNCHWITHREPOS Synchronize
advance and
main part of
program, e.g.
switch on open-
loop axis control
(VDI signal:
follow-up mode)
11. INTERRUPT Carry out user
interrupt "ASUP“
(VDI signal:
digital-analog
interface, ASUP
interface).
1. the channel is active due to block
search or machine data loading
2. the channel is stopped and the
Asup ”ASUP_START_MASK”
must be started and the current
block cannot be reorganized.
3. Digitalize is selected
4. reference-point approach has not
yet been carried out
5. the current block in which program
execution has been stopped can-
not be reorganized, since decel-
eration is carried out aver several
blocks.
⇒ Wait until block search or
machine data loading is com-
pleted, or press the RESET
key to abort the program
⇒ Activate block change as long
as the NC block can be reor-
ganized.
⇒ Deselect Digitalize
⇒ Carry out reference-point
approach or ignore this condi-
tion by setting the machine
data ”ASUP_START_MASK”.
⇒ Abort program
12. INTERRUPTFASTLIFT-OFF Carry out user
interrupt "ASUP“
with quick lifting
(VDI signal:
digital-analog
interface)
See 11
13. INTERRUPTBLSYNC Carry out user
interrupt at end of
block
(VDI signal:
digital-analog
interface)
See 11
