Siemens SINUMERIK 802C Diagnostics Guide

1 Alarms 01.02
6FC5598-3AA20-0BP2 © Siemens AG 2002 All Rights Reserved
1-98 SINUMERIK 802S/802C (DG)
No./Name Explanation Not allowed if Remedy
14. FASTLIFTOFF Carry out quick
lifting
(VDI signal:
digital-analog
interface and
ASUP interface,
further actions
are: 11, 12, 13,
88, 89).
15. TM_MOVETOOL Move tool
- with tool man-
agement only -
(PI command)
16. DELDISTOGO Carry out "Delete
distance to go"
(VDI signal:
Delete distance
to go, synchro-
nous response)
1. too high nesting depth
2. the current block in which program
execution is stopped cannot be
reorganized, since deceleration is
carried out over several blocks.
⇒ Abort program
⇒ Abort program
17. FASTDELDISTOGO Carry out "Delete
distance to go
quickly". Block
execution is not
reorganized (VDI
signal: Delete
distance to go,
synchronous
response)
18. DELDISTOGOWITHOUT_STOP Carry out "Delete
distance to go
quickly". Reor-
ganization and
stop movement
are not carried
out.
(VDI signal:
Delete distance
to go, synchro-
nous response)
19. PROGRESETREPEAT Abort subroutine
repetition (VDI
signal: Delete
number of
subroutine
passes)
1. too high nesting depth
2. the current block in which program
execution is stopped cannot be
reorganized, since deceleration is
carried out over several blocks.
⇒ Abort program
⇒ Abort program
20. PROGCANCELSUB Abort subroutine
execution (VDI
signal: program
level abortion)
3. too high nesting depth
4. the current block in which program
execution is stopped cannot be
reorganized, since deceleration is
carried out over several blocks.
⇒ Abort program
⇒ Abort program
21. SINGLEBLOCKSTOP Activate single
block
(VDI signal:
Activate single
block)
22. SINGLEBLOCKOFF Switch off single
block.
(VDI signal:
Activate single
block)
23. SINGLEBLOCK_IPO Activate main run
single block
(BTSS variable
and VDI signal:
Activate single
block)
24. SINGLEBLOCK_
DECODIER
Activate decod-
ing single block
(BTSS variable
and VDI signal:
Activate single
block)
1. too high nesting depth
2. the current block in which program
execution is stopped cannot be
reorganized, since deceleration is
carried out over several blocks.
⇒ Wait until the preceding Asup
is completed, or abort pro-
gram
⇒ Abort program
