10 Operating Instructions, 12/2012, 6FC5397-2EP10-0BA0
Input/output DB number Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
DB1000.DBB2 100
(INC)
10 (INC) 1 (INC) Key 21 Key 20 Key 19 Key 18 Key 17
DB1000.DBB3 Key 32 Key 31 Cycle
start
Cycle
Stop
RESET Spindle
right
Spindle
Stop
Spindle
left
DB1000.DBB4 Key 39 Key 38 Key 37 Key 36 RAPID Key 34 Key 33
DB1000.DBB5
DB1000.DBB6
DB1000.DBB7
DB1000.DBB8 Feed override value (in Gray code)
DB1000.DBB9 Spindle override value (in Gray code)
DB1000.DBB10
DB1100.DBB0 LED 8 LED 7 LED 6 LED 5 LED 4 LED 3 LED 2 LED 1
DB1100.DBB1 LED
16
LED 15 LED 14 LED 13 LED 12 LED 11 LED 10 LED 9
DB1100.DBB2 LED
24
LED 23 LED 22 LED 21 LED 20 LED 19 LED 18 LED 17
DB1100.DBB3 LED 30 LED 29 LED 28 LED 27 LED 26 LED 25
DB1100.DBB4
DB1100.DBB5
DB1100.DBB6
DB1100.DBB7
DB1100.DBB8 7 SEG LED 1
DB1100.DBB9 7SEG LED 2
DB1100.DBB10
DB1100.DBB11
Output (PPU -
> MCP),
DB1100
DB1100.DBB12 DP 2
2)
DP 1
1)
1)
The decimal point of the 7 SEG LED 1.
2)
The decimal point of the 7 SEG LED 2.
Note
Interfaces where nothing has been entered are reserved for the next version.
You can understand the relationship between the PLC interface addresses and the
SINUMERIK 808D MCP from the illustration below:
