Descriptions of the PLC subroutines
3.32 Subroutine 60 - Disk_MGZ_M (disk-style tool magazine for milling)
PLC Subroutines Manual
74 Operating Instructions, 12/2012, 6FC5397-2EP10-0BA0
Name Type Description
MgzSp_pos BOOL Tool magazine has reached the spindle position
MgzOrg_pos BOOL Tool magazine has reached the original position
T_rel_pos BOOL Release position fort he tool magazine
T_lck_pos BOOL Clamping position for the tool magazine
T_rel_k BOOL Tool release key for the spindle
T_rel_EnK BOOL Enabling key for the tool release of the spindle
Table 3- 40 Outputs
Name Type Description
MgzCW_o BOOL Clockwise rotation of the tool magazine
MgzCCW_o BOOL Counter-clockwise rotation of the tool magazine
MgzSp_o BOOL The spindle position for the tool magazine
MgzOrg_o BOOL The original position for the tool magazine
SpRelT_o BOOL Releasing a tool
RelT_En_o BOOL Enabling releasing a tool
MgzSp_LED BOOL Magazine reaches spindle position
MgzOrg_LED BOOL Magazine reaches original position
Assigned global variables
MgzCW_cmd BOOL M230.0 Command for clockwise rotation of the tool magazine
MgzCCW_cmd BOOL M230.1 Command for counter-clockwise rotation of the tool
magazine
Mgz_rot_CMD BOOL DB4900.DBB24 Tool change command from the tool change subroutine
Relevant PLC machine data
None
