Use of user alarms in the PLC subroutines
PLC Subroutines Manual
78 Operating Instructions, 12/2012, 6FC5397-2EP10-0BA0
Alarm No. Interface Address Alarm Description From SBR
700035 DB1600.DBX4.3 Spindle not reach tool-release pos. in
time
SBR60: Disk_MGZ_M
700036 DB1600.DBX4.4 Spindle not reach tool-lock pos. in time SBR60: Disk_MGZ_M
700049 DB1600.DBX6.1 Reference point X-axis not reached SBR58: MM_MAIN
700050 DB1600.DBX6.2 Reference point Z-axis not reached SBR58: MM_MAIN
700051 DB1600.DBX6.3 Wrong spindle direction started SBR58: MM_MAIN
700052 DB1600.DBX6.4 Watchdog timer JOG-program SBR58: MM_MAIN
700053 DB1600.DBX6.5 Spindle override not 100% SBR58: MM_MAIN
700054 DB1600.DBX6.6 Spindle is not started SBR58: MM_MAIN
700055 DB1600.DBX6.7 Feed override = 0% SBR58: MM_MAIN
700056 DB1600.DBX7.0 Change of spindle direction not
possible in thread
SBR58: MM_MAIN
700059 DB1600.DBX7.3 Safe door not closed, NC start not
possible
SBR22:
AUX_SAFE_DOOR
700060 DB1600.DBX7.4 Channel not in reset, change PRT not
possible
SBR37: MCP_NCK
