PLC sample applications
5.2 PLC sample application (milling)
PLC Subroutines Manual
Operating Instructions, 12/2012, 6FC5397-2EP10-0BA0
83
Signal Description Remark
I2.7 Lubrication pump motor overload Normally closed
I3.0 Reserved
I3.1 Reserved
I3.2 Reserved
I3.3 Reserved
I3.4 Reserved
I3.5 Reserved
I3.6 Reserved
I3.7 Reserved
I4.0 Handheld unit: axis X selected Valid at a high level
I4.1 Handheld unit: axis Y selected Valid at a high level
I4.2 Handheld unit: axis Z selected Valid at a high level
I4.3 Handheld unit: fourth axis selected Reserved
I4.4 Handheld unit: increment X1 Valid at a high level
I4.5 Handheld unit: increment X10 Valid at a high level
I4.6 Handheld unit: increment X100 Valid at a high level
I4.7 Handheld unit: enabled Valid at a high level
Q0.0 Working lamp
Q0.1
Q0.2 Chip forward
Q0.3 Chip backward
Q0.4 Cooling pump
Q0.5 Lubrication pump
Q0.6 Safety door open
Q0.7
Q1.0 Magazine rotating clockwise
Q1.1 Magazine rotating counter-clockwise
Q1.2 Magazine approaching spindle position
Q1.3 Magazine approaching original position
Q1.4 Tool release from the spindle
Q1.5
Q1.6
Q1.7 Handheld unit valid
Table 5- 4 Definition of user-defined keys on the MCP
User-defined key 1 Working lamp
User-defined key 2 Manual cooling
User-defined key 3 Safe door
User-defined key 4 Manual clockwise rotation of the tool magazine
User-defined key 5 Manual reset of the tool magazine
User-defined key 6 Manual counter-clockwise rotation of the tool magazine
User-defined key 7 Removing chip forward
User-defined key 8 Removing chip backward
