808D Page 13 Operating and Programming — Milling
Tool Setup
s
Content
SEQUENCE
Unit Description
This unit describes how to create and set up tools.
Unit Content
Create tool
Load tool
into active
position
Measure
tool
Move ma-
chine with
handwheel
JOG
spindle
Execute M
function
Start
spindle
Create tool
A tool must have been created and
measured before executing the pro-
gram.
Step 1
Press “Offset” on the PPU.
Please make sure the system is in JOG mode.
Create tool
edge
Press the “Tool list” SK on the PPU.
End
To Next Page
