Siemens SINUMERIK 880 GA2 Planning Guide

9 Examples 01.91
9.2.27 FB 189 Delete last cutting edge
Display description Comment
151413121110987654321 0
DW 48 Magazine number
DW 49 Locator number
DW 50 Pointer
DW 51 Cutting edge number
DW 52 Text pointer (user-specific text)
DW 53 Cutting edge number memory FB 189
DW 54 Unassigned
DW 55 Unassigned
Address key
DB 146
Interface for the calling program FB 160:
F 224.0 = General disable flag
As long as this flag is set, FB 160 accepts no operator inputs.
F 228.6 = Dynamic function flag
When the "Delete last cutting edge"softkey is operated, FB 160 calls FB 189 and flag F 228.6
is set for the duration of one cycle.
F 229.6 = Static function flag
Flag F 229.6 is set by FB 189 in the first cycle and reset after completion of the function. As
long as this flag is set, FB 189 is called cyclically by FB 160.
