11.92 5 Configuring
5.5 FB 120 Unloading via tape
Save from to: Function code: 1
Unload magazines x to y, where the following restrictions must be observed.
1 < = x < = y <= 16
Parameters:
– First magazine (x) DB135 DR 18
– Last magazine (y) DB135 DL 18
Save chained: Function code: 2
Unloading of chained magazines starting from magazine x, the way in which
the magazines are chained is defined.
Case 1: Starting from magazine x up to the magazine to which no other
magazine is assigned.
Case 2: Starting from magazine x up to the magazine which is again
chained with magazine x.
Parameters:
– Starting magazine (x) DB135 DR 18
Save Hand marked: Function code: 3
The user can unload tools which have been marked manually
(operator panel) in DB153 with data bit 7.
Parameters:
None
© Siemens AG 1991 All Rights Reserved 6FC5 197-0AA40-1BP1 5–17
SINUMERIK 840/880 (PJ)
