Siemens SINUMERIK ONE MCP 1900.2 - Dimension Drawings

Dimension drawings
3
3Y
q
q



*) Plus wiring portion
Figure3-1 Front, rear, and side view of MCP 1900.2 (all speci󹪝cations in mm)
The installation clearance for the MCPs is 70mm including the wiring portion.
ONE MCP Part 2: MCP 1900.2
Equipment Manual, 01/2023, A5E52559449B AA 15
