Machining the Workpiece 08/2005
3.5 Startin
the machinin
at a s
ecific
oint in the
ro
ram
3
♥ Siemens AG, 2005. All rights reserved
3-100 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
Specify target directly
îš¾ Load a program in "Machine Auto" mode (see Sec.
"Starting/stopping machining").
Search
pointer
îš¾ Press the "Block search" and "Search pointer" softkeys.
îš¾ Specify the desired target.
To
contour
...
External -
without cal.
îš¾ Select a calculation technique.
Cycle Start
îš¾ Press the "Cycle Start" key.
ShopTurn carries out all necessary pre-settings.
Cycle Start
îš¾ Press the "Cycle Start" key again.
The new starting position is approached. The program executes from
the beginning or end of the target block, depending on the calculation
technique.
Reset
You can abort the search by pressing the "Reset" key.
Searching for any text
îš¾ Load a program in "Machine Auto" mode (see Sec.
"Starting/stopping machining").
Search
îš¾ Press the "Block search" and "Search" softkeys.
îš¾ Enter the text string that you want to locate.
îš¾ Select whether the search is to commence at the start of the
program or the current cursor position.
Search
îš¾ Press the "Search" softkey.
The program block that contains the text string is marked.
Find
next
îš¾ Press the "Find next" softkey, if you want to continue the search.
Start
search run
îš¾ Press the "Abort" and "Start search run" softkeys.
îš¾ Where chained program blocks have several technology blocks,
select the desired technology block in the "Search run" window
and press the "Accept" softkey.
The prompt does not appear in the case of single program blocks.
îš¾ For chained program blocks, enter the number for the desired
starting position and press the "Accept" softkey.
The prompt does not appear in the case of single program blocks.
