5
ShopTurn Functions 08/2005
5.15 Teachin
5
♥ Siemens AG, 2005. All rights reserved
5-330 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
5.15.2 Teaching a position sample
You can teach any position sample.
Sequence of operations
1. Creating a program
2. Programming technology cycles and positions/position samples
Program the desired drilling/milling cycles and the position sample
(see “Drilling", “Trimming”, and “Positions and Position sample”).
3. Execution
Position the cursor on the position sample and press the "Execute"
softkey.
A block search is automatically triggered and you will receive a
query.
4. Select the work step and the position sample.
5. NC Start
Fit the tool with “Cycle Start”, and then start machining using the
"Cycle Start" key.
Program the next machining step the same way if the machining
provided the desired results, or repeat steps 2 through 5 for the
program block.
You can simulate machining before every execution in order to control
the machining results.
