5
ShopTurn Functions 08/2005
5.1 Strai
ht or circular
ath movements
5
♥ Siemens AG, 2005. All rights reserved
5-156 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
5.1.1 Select tool and machining plane
Before you can program a line or circle, you have to select the tool,
spindle, spindle speed and machining plane.
If you program a sequence of different straight or circular path
motions, the settings for the tool, spindle, spindle speed and
machining plane remain active until you change them again.
If you change the selected machining plane subsequently, the
coordinates of the programmed path motion are adjusted
automatically to the new machining plane. The originally programmed
coordinates remain unchanged only for a straight motion (right-angled,
not polar).
Tool >
¾ Press the "Strai. Circle" and "Tool" soft keys.
¾ Enter a tool in parameter field "T".
-or-
Tools
¾ Press the "Tools" soft key and select a tool from the tool list.
-and-
¾ Place the cursor on the tool that you want to use for machining.
-and-
To
Program
¾ Press the "To Program" softkey.
The tool is copied into the "T" parameter field.
¾ Select the tool cutting edge number D if the tool has several
cutting edges.
¾ In the left-hand input field of the Spindle parameter, select main
spindle (S1), tool spindle (S2) or counterspindle (S3).
¾ Enter the spindle speed or cutting rate in the right-hand input field.
