08/2005 Working with Manual Machine
6.3 Sim
p
le work
p
iece machinin
g
in manual mode
6
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 6-337
Parameter Description Unit
T Tool
F Machining feedrate mm/min
mm/rot.
S1 Main spindle rpm
m/min
S2 Tool spindle rpm
Direction of
rotation
: Spindle is turning counterclockwise
: Spindle rotates right
: Spindle stops
: No change
6.3.2 Taper turning
The basic effective direction can be selected via the axis direction
keys or via the cross-switching lever. In addition, an angle (α
) can also
be input.
Jog
Taper
turning
 Press the "Taper turning" softkey in "Manual Machine" mode.
 Select the tool, spindle, and spindle direction and specify the
machining feedrate.
 Input the desired angle α.
Selecting/deselecting the taper turning and changing the angle α is
only possible in the reset state.
Parameter Description Unit
T, F. S See Sec. “Traversing the Axes“
α
Turning of the coordinate system
Degrees
