5
ShopTurn Functions 08/2005
5.1 Strai
g
ht or circular
p
ath movements
5
♥ Siemens AG, 2005. All rights reserved
5-162 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
Circle
radius >
¾ Press the "Strai. Circle" and "Circle radius" soft keys.
Parameters Description Unit
Direction of
rotation
Direction of rotation in which the tool travels from the circle starting point to the circle
end point
Direction of rotation clockwise (right)
Direction of rotation counterclockwise (left)
X
Y
Machining plane End face/End face C:
Target position in the X direction (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
Target position in the Y direction (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
mm
mm
Y
Z
Machining plane Peripheral surface/Peripheral surface C:
Target position in the Y direction (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
Target position in the Z direction (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
mm
mm
X
Y
Machining plane End face Y:
Target position in the X direction (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
Target position in the Y direction (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
mm
mm
Y
Z
Machining plane Peripheral surface Y:
Target position in the Y direction (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
Target position in the Z direction (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
mm
mm
X
Z
Machining plane Rotate:
Target position ¬ in the X direction (abs) or target position in the X direction (inc)
Incremental dimensions: The plus/minus sign is evaluated.
Target position in the Z direction (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
mm
mm
R Radius of arc
The sign determines the type of arc traversed.
mm
F Machining feedrate mm/rev
mm/min
mm/tooth
