5
ShopTurn Functions 08/2005
5.2 Drillin
g
5
♥ Siemens AG, 2005. All rights reserved
5-184 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
Z0
X0
Y0
α0
αX
αY
L1
L2
N1
N2
End face/End face C:
Z coordinate of the reference point (abs.)
X coordinate of the reference point – first position (abs.)
Y coordinate of the reference point – first position (abs.)
Angle of rotation of matrix
Positive angle: Matrix is rotated counterclockwise.
Negative angle: Matrix is rotated clockwise.
Shear angle of matrix relative to X axis
Positive angle: Matrix is rotated counterclockwise.
Negative angle: Matrix is rotated clockwise.
Shear angle of matrix relative to Y axis
Positive angle: Matrix is rotated counterclockwise.
Negative angle: Matrix is rotated clockwise.
Column spacing in X direction
Line spacing in Y direction
Number of columns in X direction
Number of lines in Y direction
mm
mm
mm
Degrees
Degrees
Degrees
mm
mm
X0
Y0
Z0
α0
αX
αY
L1
L2
N1
N2
Peripheral surface/Peripheral surface C:
Cylinder diameter ¬ (abs.)
Y coordinate of the reference point – first position (abs.)
Z coordinate of the reference point – first position (abs.)
Angle of rotation of matrix
Positive angle: Matrix is rotated counter-clockwise
Negative angle: Matrix is rotated in CW direction.
Shear angle of matrix relative to X axis
Positive angle: Matrix is rotated counter-clockwise
Negative angle: Matrix is rotated in CW direction.
Shear angle of matrix relative to Y axis
Positive angle: Matrix is rotated counter-clockwise
Negative angle: Matrix is rotated in CW direction.
Column spacing in Y direction
Line spacing in Z direction
Number of columns in Y direction
Number of lines in Z direction
mm
mm
mm
Degrees
Degrees
Degrees
mm
mm
