5.5 Millin
5
♥ Siemens AG, 2005. All rights reserved
5-252 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
DYZ
DX
UYZ
UX
FS
ZFS
Maximum infeed in the YZ plane
Plane infeed in %: Ratio of plane infeed (mm) to milling cutter diameter (mm) – (for
roughing and finishing only)
Maximum depth infeed (X direction) – (for roughing and finishing only)
Finishing allowance in the plane (slot edge) – (for roughing and finishing only)
Finishing allowance in depth (slot base) – (for roughing and finishing only)
Chamfer width (inc) – (for chamfer only)
Insertion depth of tool tip (abs or inc) -- (for chamfer only)
mm
%
mm
mm
mm
mm
mm
CP
X0
Y0
L0
C0
Z0
Z1
DXY
DZ
UXY
UZ
FS
ZFS
Single position End face Y:
The reference point is always the center point of the longitudinal slot.
Positioning angle for machining area
Reference point in X direction (abs.)
Reference point in Y direction (abs.)
Reference point on longitudinal polar axis (alternative to X0)
Reference point on angular polar axis (alternative to Y0)
Reference point in Z direction (abs.)
Slot depth based on Z0 (abs or inc) – (only for roughing and finishing)
Maximum infeed in the XY plane
Plane infeed in %: Ratio of plane infeed (mm) to milling cutter diameter (mm) – (for
roughing and finishing only)
Maximum depth infeed (Z direction) – (for roughing and finishing only)
Finishing allowance in the plane (slot edge) – (for roughing and finishing only)
Finishing allowance in depth (slot base) – (for roughing and finishing only)
Chamfer width (inc) – (for chamfer only)
Insertion depth of tool tip (abs or inc) -- (for chamfer only)
Degrees
mm
mm
mm
Degrees
mm
mm
mm
%
mm
mm
mm
mm
mm
C0
Y0
Z0
X0
X1
DYZ
DX
UYZ
UX
FS
ZFS
Single position Peripheral surface Y:
The reference point is always the center point of the longitudinal slot.
Reference point
Reference point in Y direction (abs.)
Reference point in Z direction (abs.)
Reference point (abs)
Slot depth based on X0 (abs or inc) – (only for roughing and finishing)
Maximum infeed in the YZ plane
Plane infeed in %: Ratio of plane infeed (mm) to milling cutter diameter (mm) – (for
roughing and finishing only)
Maximum depth infeed (X direction) – (for roughing and finishing only)
Finishing allowance in the plane (slot edge) – (for roughing and finishing only)
Finishing allowance in depth (slot base) – (for roughing and finishing only)
Chamfer width (inc) (for chamfer only)
Insertion depth of tool tip (abs or inc) -- (for chamfer only)
Degrees
mm
mm
mm
mm
mm
%
mm
mm
mm
mm
mm
W Slot width
mm
L Slot length
mm
α0
Angle of rotation of slot
Face: α0 refers to the X axis or to the position of C0 with a polar reference point
Peripheral surface: α0 refers to the Y axis
Degrees
Insertion Insertion strategy
Central: Vertical insertion at center of slot
The tool executes the depth infeed vertically in the center of the slot.
Note: This setting can be used only if the cutter can cut across center.
mm
