5
ShopTurn Functions 08/2005
5.5 Millin
g
5
♥ Siemens AG, 2005. All rights reserved
5-266 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
C0
Y0
R
Z0
α0
X0
X1
FX
W
DY1
DY2
α1
α2
YM
ZM
Peripheral surface Y:
Reference point
Reference point in Y direction (abs.)
Reference point on longitudinal polar axis (alternative to Y0) – (for curved alignment
only)
Reference point in Z direction (abs.)
Reference point on angular polar axis (alternative to Z0) – (for curved alignment
only)
Reference point in X direction (abs.)
Machining depth (inc.)
Depth infeed rate
Character height
Character spacing
Total width (alternative to DY1) – (for linear alignment only)
Text direction (for linear alignment only)
Arc angle (alternative to DY1) – (for curved alignment only)
Center point of arc (abs.) – (for curved alignment only)
Center point of arc (abs.) – (for curved alignment only)
mm
mm
mm
mm
Degrees
mm
mm
mm/min
mm/tooth
mm
mm
mm
Degrees
Degrees
mm
mm
