5
08/2005 ShopTurn Functions
5.9 Machinin
with the counters
indle
5
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 5-319
Parameters Description Unit
Function Select from five different functions:
Gripping
Pulling
Rear side
Front side
Complete
Park position
XP
ZP
Rinse chuck
S
Direction of
rotation
Gripping:
WCS: The park position is entered into the workpiece coordinate system
MCS: The park position is entered into the machine coordinate system; teaching
of the park position and the angular offset is possible
Park position of the tool in the X direction (abs)
Park position of tool in Z direction (abs)
Rinse counterspindle chuck or not
Spindle speed (main spindle and counterspindle)
Direction of rotation (main spindle and counterspindle):
Direction of rotation clockwise (right)
Direction of rotation counterclockwise (left)
No spindle rotation
mm
mm
rpm
α1
Z1
ZR
FR
Fixed stop
Angular offset of counterspindle on gripping
Transfer position (abs.)
Position at which traversal at reduced feedrate starts (abs or inc)
Reduced feedrate
Yes: The counterspindle comes to a halt a specified distance from the
transfer position Z1 and then traverses at the specified feedrate
as far as the limit stop.
No: The counterspindle traverses to the transfer position Z1.
Degrees
mm
mm
mm/min
Work offset
Z1
F
Pulling:
Work offset in which the coordinate system displaced by Z1 must be saved.
Amount by which the workpiece is pulled out of the main spindle (inc)
Feedrate
mm
mm/min
Work offset
ZnW
ZV
Rear side:
Work offset in which the coordinate system, which was shifted according to ZW and
by ZV as well as mirrored in Z, must be saved.
Machining position for special axis (abs.); machine coordinating system
Workpiece zero offset in Z direction (inc, the sign is also evaluated)
mm
mm
Work offset
Front face:
Work offset for machining the next front face
