Note
Settable work offsets
The labeling of the softkeys for the settable work offsets varies, i.e. the settable work offsets
configured on the machine are displayed (examples: G54…G57, G54…G505, G54…G599).
Please refer to the machine manufacturer's specifications.
Automatic measurement
1. Select the "Measure workpiece zero" function (see steps 1 and 2 above).
2. Press the "Rectangular spigot" softkey.
- OR -
Press the "1 circular spigot" softkey.
- OR -
Press the "2 circular spigots" softkey.
- OR -
Press the "3 circular spigots" softkey.
- OR -
Press the "4 circular spigots" softkey.
- OR -
If these softkeys are not listed, press any vertical softkey (with the excep‐
tion of "Set edge") and in the drop-down list, select the desired measure‐
ment version.
3. Traverse the workpiece probe to approximately the center above the rec‐
tangular or circular spigot, or for several, above the first spigot to be
measured.
4. Specify whether you want "Measurement only" or in which work offset
you want to store the zero point.
Rectangular
spigot
5. ● Enter the infeed value in "DZ" to determine the measuring depth.
● In field "L" enter the length (1st geometry axis of the working plane)
and in field "W" the width (2nd geometry axis of the working plane) of
the spigot.
- OR -
1 circular
spigot
● Enter the approximate diameter of the spigot into "Øspigot".
● Enter an angle in "Probe angle". With the probe angle you can turn
the traversing direction of the probe through any angle.
- OR -
Setting up the machine
4.6 Measuring the workpiece zero
Milling
132 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
