Parameters, G code program Parameters, ShopMill program
PRG Name of the program to be generated T Tool name
PL Machining plane F Feedrate mm/min
mm/tooth
Milling direction
● Synchronous
operation
● Up-cut
operation
S / V Spindle speed or constant cutting
rate
rpm
m/min
RP Retraction plane mm
SC Safety clearance mm
F Feedrate mm/min
Parameter Description Unit
Machining The following machining operations can be selected:
∇ (roughing)
TR Reference tool Tool, which is used in the "Stock removal" machining step. Is used to
determine the residual material.
D Cutting edge number
Z0 Reference point in the tool axis Z mm
Z1 Pocket depth (abs) or depth referred to Z0 (inc) mm
DXY
● Maximum plane infeed
● Maximum plane infeed as a percentage of the milling cutter diameter
mm
%
DZ Maximum depth infeed mm
UXY Finishing allowance, plane mm
UZ Finishing allowance, depth mm
Lift mode Lift mode before new infeed
If the machining operation requires several points of insertion, the retraction height to
which the tool is retracted, is selected as follows:
● To retraction plane
● Z0 + safety clearance
If there are no elements larger than Z0 in the pocket area, "Z0 + safety clearance" can
be selected as the lift mode.
mm
mm
10.3.12 Milling contour spigot (CYCLE63)
Function
You can mill any spigot using the "Mill spigot" cycle.
Programming technological functions (cycles)
10.3 Contour milling
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 507
