In addition to the offset (course and fine), the associated rotation, scaling and mirroring are
also displayed.
This window is generally used only for monitoring.
Display of active work offsets
Work offsets
MCS actual value Display of the actual value in the Machine Coordinate Sys‐
tem.
Kin. trans. workpiece Displays the additional work offsets programmed with
$P_TRAFRAME_P.
Kin. trans. tool Displays the additional work offsets programmed with
$P_TRAFRAME_T.
DRF Displays the handwheel axis offset.
$AA_OFF overlay Displays the overlaid movement programmed with
$AA_OFF.
Basic reference Displays the additional work offsets programmed with
$P_SETFRAME.
Access to the system offsets is protected via a keyswitch.
External WO frame Displays the additional work offsets programmed with
$P_EXTFRAME.
Total base WO Displays all effective basis offsets.
G500 Displays the work offsets activated with G54 - G599.
Under certain circumstances, you can change the data us‐
ing "Set WO", i.e. you can correct a zero point that has been
set.
Tool reference Displays the additional work offsets programmed with
$P_TOOLFRAME.
Workpiece reference Displays the additional work offsets programmed with
$P_WPFRAME.
Transformer reference Displays the additional work offsets programmed with
$P_TRAFRAME.
Programmed WO Displays the additional work offsets programmed with
$P_PFRAME.
Cycle reference Displays the additional work offsets programmed with
$P_CYCFRAME.
Total WO Displays the active work offset, resulting from the total of all
work offsets.
T: Displays the active tool.
WCS actual value Displays the actual value in the Workpiece Coordinate Sys‐
tem.
The display of the zero point offsets depends on the settings.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Setting up the machine
4.8 Zero offsets
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 147
